ZY-CD01 1080P 4G GPS AI Dashcam Dual Camera Car Video Recorder Car Black Box Fleet Dash Cam Camera
Features
|
System |
OS |
Linux System NPU Computing Power: 1Tops |
|
Storage |
RAM: DDR 4Gbit; ROM: 1Gbit;TF Card: Single card (maximum support for 1TB) |
RAM: DDR 4Gbit; ROM: 1Gbit;TF Card: Single card (maximum support for 1TB) |
|
Buttons |
Mechanical Button |
1 Button: Reset |
|
Functions & Interfaces |
Camera |
Front ADAS Camera: 1920*1080P@25fps Internal DMS Camera:19201080P@25fps |
|
|
4G |
Built-in 4G Cat1 Module, Built-in FPC Antenna LTE-FDD: B1, B3, B5, B8 LTE-TDD: B34, B38, B39, B40, B41 |
|
|
GPS/BD |
Supports Beidou/GPS Combined Positioning or Single Beidou Dual-Frequency Positioning; Supports Geofencing Function |
|
|
WIFI |
Built-in WIFI Module, Built-in FPC Antenna |
|
|
Gravity Sensor |
Built-in G-sensor (3-axis) |
|
|
Speaker |
Built-in 8Ω 1.5W Speaker |
|
|
MIC |
Built-in MIC |
|
|
Display |
Supports mobile APP connection to the device's hot spot for viewing image display and configuring parameters |
|
|
LED Lights |
3 LEDs: Recording Status, 4G Network, Positioning Status |
|
|
RTC |
Built-in Independent RTC Clock Chip |
|
|
Battery/Super Capacitor |
Built-in RTC Independent Battery, Built-in 10μF Super Capacitor |
|
|
Serial Port |
Supports 1 serial port and 1 RS485 port, which can be connected to OBD, radar, fuel sensor, etc. |
|
|
CAN |
Supports 1 CAN Port |
|
|
IO |
1 Input, 1 Output, 1 Emergency Alarm Button |
|
|
Power Input |
Powered by BMW Cable, 9-36V |
|
Multimedia |
Video Format |
Supports H.264/H.265 Encoding |
|
|
Audio Format |
AAC / G711 |
|
Algorithm Functions |
ADAS |
Lane Departure Warning, Forward Collision Warning (Excessive Proximity to Vehicles), Pedestrian Detection, Speed Limit Sign Recognition |
|
|
DMS |
Driver (Main): Fatigue Driving, Making/Answering Calls, Smoking, Seat belt Detection, Inattention, Camera Obstruction, Driver Abnormality Passenger (Co-pilot): Seat belt Detection |
|
Software Protocols |
JT/T808, JT/T1078, GB/T28181 |
JT/T808, JT/T1078, GB/T28181 |
|
Input Voltage |
Input Voltage: 9-36V; Supports 12V / 24V System Power Supply |
Input Voltage: 9-36V; Supports 12V / 24V System Power Supply |
|
Current |
Operating Current: Powered by 12V, normal operating current 250mA, maximum 350mAStandby Current: Powered by 12V, standby current less than 2mA |
Operating Current: Powered by 12V, normal operating current 250mA, maximum 350mAStandby Current: Powered by 12V, standby current less than 2mA |
