ZY-S51 Car SD Card Video Recorder

product details

product description

(full built-in/partial standard protocol/H.265/4+1 video input)

Product introduction

ZY-S51 is a new generation of video surveillance products integrating video surveillance and Beidou positioning. This product has rich functions and strong expansibility.

It adopts a new generation of audio and video dedicated high-speed processor and embedded operating system, combined with H.264/H.265 video compression, satellite positioning, CAN, 232/485 serial port, 3G/4G network and other technologies, it can realize audio and video recording, Wireless data uploading provides vehicle operating companies with a wealth of driving data and audio and video images to facilitate more precise management of vehicles and drivers.

description2

Features

Comply with the "Technical Requirements for On-board Video Terminals of Satellite Positioning Systems for Road Transport Vehicles" (JT/T 1076-2016) standard;

Comply with the "Road Transport Vehicle Satellite Positioning System Video Communication Protocol" (JT/T 1078-2016) standard;

Comply with the "Communication Protocol and Data Format of On-board Terminal of Road Transport Vehicle Satellite System" (JT/T 808-2019) standard;

Support 4 channels of analog audio and video signal input and 1 channel of IPC signal input. The analog channel supports up to 4 channels of 1080P encoding, and the digital channel supports up to 1080P encoding. Adopt H.265 encoding and compression technology;

It can support up to 2 SD/SDHC cards, and a single SD card can support 256G;

Built-in full Netcom 4G module, support wireless communication network based on LTE-TDD/LTE-FDD/WCDMA/TD-SCDMA/EVDO/CDMA/GSM;

Built-in high-sensitivity Beidou and GPS dual-mode positioning module;

Support wide-range power input (DC +8 ~ +36V) to meet the requirements of vehicle electrical characteristics;

With power-off protection function, it can also protect the integrity of key data in the event of a sudden power failure;

Optional built-in ADAS/DSM/BSD; can realize fatigue detection and warning, driver identification, yawning, smoking, making phone calls, not wearing seat belts, driver looking left and right, lane departure, collision warning, blind spot detection, etc.

Abundant expansion interfaces, supporting the access of peripheral devices such as smart display terminals, oil poles, temperature and humidity/load;

description2

Technical parameters

model	ZY-S51
video compression standard	H.265/H.264
audio compression standard	G.711A
Resolution	1080P/720P/4CIF/CIF
Video input and output	Video input: 4 analog/AHD HD, 1 digital HD Video output: 1 channel CVBS/VGA (choose one out of two)
Audio input and output	Audio input: 4 channels, 3Vp-p linear level, 1K ohm Audio output: 1 channel, 2Vp-p linear level, 600 ohms
wireless network	Built-in 4G full Netcom module, support wireless communication network based on LTE-TDD/LTE-FDD/WCDMA/TD-SCDMA/EVDO/CDMA/GSM
positioning module	Support Beidou/GPS
Antenna interface	SMA interface
ADAS&DMS&BSD	Optional built-in
storage medium	Support 2 SD/SDHC card storage
Driving information collection	Input: 4 channels of high level trigger, 2 channels of low level trigger, 1 channel of pulse acquisition Output: 3 channels, 12V/5V output, one high level output
network port	1pc
serial data interface	1 channel RS232 interface, 1 channel 485 interface
Operation method	Infrared remote control
Device power consumption	<10W
Operating temperature/humidity	-30℃ - ＋70℃
Operating Voltage	DC8V-36V
Voice intercom	1 channel, support two-way intercom/support cluster intercom Input: 1.0Vp-p linear level, 1K ohm Output: 2.0Vp-p linear level, 600 ohms
